Performance Tuning DrawShapedText

In my last post Text Rendering in SkiaSharp and HarfBuzz I mentioned that you should use text shaping, but the default method DrawShapedText is very slow compared to DrawText.

Matthew Leibowitz replied that this could be done better when you cache some things.

@BeneStebner may know as he did the most work on the harfbuzz binding. But, the draw shaped text method is slow as it does all the loading and shaping each time. You may want to try reuse things. Also @toptensoftware is a cool guy with RichTextKit that does amazing things.

— Matthew Leibowitz (@mattleibow) September 21, 2024

So I gave that a try.

Performance tuning

1) Remember the SKShaper per Font

The standard DrawShapedText method is meant to be a replacement for DrawText. It has exactly the same parameters.

When I looked at the source, I saw that it just creates a new SKShaper for the given font and calls the overload which takes the additional SKShaper.

    public static void DrawShapedText(this SKCanvas canvas, string text, float x, float y, SKTextAlign textAlign, SKFont font, SKPaint paint)
    {
        if (string.IsNullOrEmpty(text))
            return;

        using var shaper = new SKShaper(font.Typeface);
        canvas.DrawShapedText(shaper, text, x, y, textAlign, font, paint);
    }

The SKShaper constructor loads the typeface and converts it to a HarfBuzzSharp.Font object. This already takes some time. So our easiest improvement is creating the SKShaper ourselves and caching it for the respective font.

This is a very small change everywhere where the fonts stay unchanged. The result is already very good. It renders the text in a fraction of the time of the call without SKShaper.

But we can do more.

2) Cache the Shape Result

Looking at the source of DrawShapedText you’ll see that its main work is done by shaper.Shape(text, x, y, font). That gives back a SKShaper.Result with a code point and position for each glyph. Well, when we cache the SKShaper objects for the font, why can’t we cache the results of the shaping process too?

Of course we can! In my CanvasExtensions.DrawShapedText method I cache the Result so that the text shaping does not need to be triggered at all if it is found in the cache.

This brings the execution time down to just about 50% more of the plain DrawText without text shaping.

Benchmarks

I also did benchmarks for a simple DrawText, DrawShapedText, DrawShapedText with SKShaper and with enabled caching. Here are the results for simple ASCII text.

| Method                  | Mean       | Error     | StdDev    | Gen0   | Gen1   | Allocated |
|------------------------ |-----------:|----------:|----------:|-------:|-------:|----------:|
| DrawAscii               |   7.361 us | 0.0650 us | 0.0543 us | 0.0153 |      - |     160 B |
| DrawShapedAscii         | 137.732 us | 0.6826 us | 0.5700 us | 0.2441 |      - |    3144 B |
| DrawAsciiWithShaper     |  19.096 us | 0.1436 us | 0.1273 us | 0.3052 |      - |    2744 B |
| DrawAsciiWithCache      |  10.029 us | 0.1020 us | 0.0954 us | 0.0916 | 0.0763 |     848 B |

If you draw font ligatures, the shaper has more work, but it renders fewer glyphs. So even though the input string is of similar length, the time cannot really be compared to the ASCII text.

| Method                  | Mean       | Error     | StdDev    | Gen0   | Gen1   | Allocated |
|------------------------ |-----------:|----------:|----------:|-------:|-------:|----------:|
| DrawLigatures           |   6.265 us | 0.0220 us | 0.0206 us | 0.0153 |      - |     160 B |
| DrawShapedLigatures     | 198.068 us | 0.4889 us | 0.3817 us | 0.2441 |      - |    3144 B |
| DrawLigaturesWithShaper |  72.899 us | 0.5071 us | 0.4496 us | 0.2441 |      - |    2744 B |
| DrawLigaturesWithCache  |   8.631 us | 0.0900 us | 0.0798 us | 0.0916 | 0.0763 |     848 B |

The same with emojis. There are less glyphs, but with different colors and a different font.

| Method                  | Mean       | Error     | StdDev    | Gen0   | Gen1   | Allocated |
|------------------------ |-----------:|----------:|----------:|-------:|-------:|----------:|
| DrawEmojis              |   7.612 us | 0.0242 us | 0.0215 us | 0.0153 |      - |     160 B |
| DrawShapedEmojis        |  63.197 us | 0.4407 us | 0.4123 us | 0.1221 |      - |    1888 B |
| DrawEmojisWithShaper    |  17.559 us | 0.0873 us | 0.0817 us | 0.1526 |      - |    1488 B |
| DrawEmojisWithCache     |  13.922 us | 0.1264 us | 0.1182 us | 0.0916 | 0.0610 |     848 B |

CanvasExtensions

I copied the CanvasExtensions from SkiaSharp.HarfBuzz and added the caching functionality. This class can be found in CanvasExtensions.cs. For simplicity I removed the obsolete methods. As the API changed from 2.88 to 3.0 there were a lot of them.

By default it does not use caching. You have to enable it with a call to SetShaperCacheDuration.

    CanvasExtensions.SetShaperCacheDuration(30_000);

or

    canvas.SetShaperCacheDuration(30_000);

This caches the SKShaper and the SKShaper.Result for 30 seconds. To disable caching, set the duration to 0.

If you want to use that in your projects, you only need to copy that class and change the using from

    using SkiaSharp.HarfBuzz;

to the namespace where you put the CanvasExtensions.

I also plan to do a PR in SkiaSharp.HarfBuzz. That’s why caching is off by default. I don’t want to change the behavior of DrawShapedText. But of course you can change it in your copy however you like.

---

The code to this blog post including benchmarks and unit tests is on GitHub.
